Davey DCS150 Double Case Manual Sump Pump

$2802.00 $1,699.00
Brand Davey
Model DCS150
Availability In Stock
General information

Description

  • 1.5kW, single phase Manual Double Case Pumps

  • Able to pump clean water, sewage or ‘grey water’ of neutral pH containing up to 10% of small soft organic solids (<10mm OD)

  • Suitable for fish ponds or aquaculture applications



Applications

  • Dirty water pumping

  • Sump emptying

  • Septic effluent water disposal

  • Pumping of waste water with small soft solids in suspensions

  • Pumping in partially submerged application



WHY CHOOSE THE DAVEY DEWATERING SUMP PUMP?

Davey Sump Pumps are used to remove water that has accumulated in a sump or pit, as well as emptying swimming pools and removing flood water from buildings etc.

Davey Sump Pumps are used where there is flooding and to solve water entry in basements where the water table is above the foundation.



Open impeller, semi-vortex, centrifugal design

  • Able to pump small soft solids in suspension

  • Less susceptible to blockage

Double mechanical shaft seal in oil bath with hard faced silicon carbide/ceramic seal on pump side

  • Added motor protection

  • Long service life

Sand slinger lip seal

  • Added protection

  • Long service life

Corrosive resistant 304 stainless steel outer case and strainer

  • Long service life

  • Attractive, lasting appearance

Double case with full discharge flow past internal motor shell

  • Able to operate in partially submerged installations

  • Better motor cooling for longer life

Automatic resetting thermal overload

  • Protects against overloading

In-built automatic thermal overload

  • Protects the motor in the event of blockage or voltage supply problems

HO7RNF oil resistant leads, 10 metres long with 3 pin power plug

  • Easy to connect to power supply

  • Longer life in dirty water

Hose tail provided for temporary installations;

  • Ideal for use with lay-flat hose (hose clamp not included)



Pump Range

ModelkWVoltageOutlet size
DC10M 0.1 220/240 1"
DC10A 0.1 220/240 1" with float
DCS40A 0.4 220/240 2" with float
DCS40M 0.4 220/240 2"
DCS55M 0.55 220/240 2"
DCS55A 0.55 220/240 2" with float
DCS75M 0.75 220/240 2"
DCS75A 0.75 220/240 2" with float
DCS150 1.5 220/240 2"
DCST08 0.75 415 2"





























Selection Guide:

daveysumppumpchart2



 Pump Curve



DC dewatering DC10a DCS150





Spec & Features
  • Features and technical specification of the product. Please contact us for further information and specifics.
  • Model
    DCS150
  • Supply voltage (V)
    220-240V
  • 50Hz – Phase
    Single
  • Output power (kW)
    1.50kW
  • Full Load Current (A)
    13.00A
  • Locked rotor current (A)
    48.00A
  • Warranty
    1 Year
