Yonos MAXO 25/0,5-7 PN 10

$1,129.00
Brand Wilo
Model Yonos MAXO 25/0,5-7
Availability In Stock
General information

Description

The high-efficiency pump Wilo-Yonos MAXO is the compact standard pump for commercial buildings with HVAC applications.

Thanks to its basic settings and functions with three operating modes and the green button it is very easy to set up and easy to use.

With the Wilo-Connect module the pump is expandable with further intelligent functions.



Design

Glandless circulator with threaded connection or flange connection, EC motor with automatic power adjustment.



Application

Hot-water heating systems of all kinds, air-conditioning systems, closed cooling circuits, industrial circulation systems.



 Benefits

• LED display provides complete transparency of set delivery head, speed stage or possible errors

• Simple adjustment over three speed stages when replacing an uncontrolled standard pump

• Easier electrical connection using the Wilo plug

 System availability ensured via collective fault signal

 Compact design and proven ease of use



Features

• Hydraulics with cataphoretic coating

• Threaded and flanged version ​

• LED display​

• Green button for pump setting​

• Collective fault signal (SSM)​

• Compact design​

• Electrical connection with Wilo plug



Wilo-Yonos Maxo

para

3





Spec & Features
  • Features and technical specification of the product. Please contact us for further information and specifics.
  • Model
    Yonos MAXO 25/0,5-7 PN 10
  • Type
    Hot water circulation pump
  • Maximum operating pressure PN
    10 bar
  • Head max H max
    7.5 m
  • Flow max Q max
    8.1 m³/h
  • Minimum suction head at 50 °C m
    3 m
  • Minimum suction head at 95 °C m
    10 m
  • Minimum suction head at 110 °C
    16 m
  • Energy efficiency index (EEI)
    0.20
  • Mains connection
    1~230 V ±10%, 50/60 Hz
  • Min current Imin
    0.08 A
  • Max current Imax
    1 A
  • Rated power P2
    90 W
  • Min. speed nmin
    1000 1/min
  • Max. speed nmax
    3700 1/min
  • Power consumption P1 min
    5 W
  • Power consumption P1 max
    120 W
  • Warranty
    2 years
